ProLine® XE 50 Gallon AL Smart Hybrid Electric Heat Pump Water Heater

How Do They Work?

The ProLine® Hybrid Electric water heater utilizes heat pump technology to provide a more efficient way to heat water with electricity.

• Heat from the surrounding air is pulled into the heat pump through a fan at the top
• The heat is absorbed by the refrigerant in the heat pump’s evaporator coil
• The temperature of the refrigerant is increased as it is pumped by a compressor
• Hot refrigerant is passed through the condenser coil around the tank and transfers the heat to the water

Features

• ENERGY STAR® qualified
• Exceptional Energy Efficiency – Improved efficiency designed to ensure available hot water at the lowest possible cost. Up to a 3.88 Uniform Energy Factor (UEF) rating which conserves energy
• Anti-Leak Technology – Smart sensor alerts user in the event a leak does occur for added peace of mind
• Compatible with the automatic water shutoff valve for enhanced protection (accessory kit 100356001)
• iCOMMTM Smart Connectivity allows you to monitor and control your water heater with the free iCOMM app.
• Meets the California Title 24 Joint Appendix 13 requirements. This unit is OpenADR 2.0b and NEEA Tier 3 certified.
• Meets NEEA Tier 3 of the Advanced Water Heater Specification
• 10-Year Limited Tank Warranty, 10-Year Parts Warranty, 1-Year Labor Warranty for Residential applications
• Dual 4500 watt Copper sheathed “backup” heating elements
• Advanced electronic control system provides large LCD display for ease of use, precise temperature control and operational status
• Glass-lined tank with CoreGardTM anode rod protects against corrosion
• “Environmentally-Friendly” Non-CFC foam insulation
• Factory-installed temperature & pressure (T&P) relief valve

Four Operating Modes:

• Efficiency (heat pump only)
• Hybrid (heat pump with electric backup)
• Electric (electric only)
• Vacation

Features

ProLine® AL combines annual savings up to $600 per year* on utility bills with new anti-leak features for added peace of mind. It offers premium features including iCOMM™ Smart Connectivity, a user-friendly display, vacation mode to save money while you are away, and a heavy duty smart anode that adapts to local water conditions to protect and extend the life of the water heater. In addition to the heat pump technology, this model also has two backup electric heating elements that help the water heater recover quickly during periods of high demand. The ProLine® AL is Northwest Energy Efficiency Alliance (NEEA) Tier 4 qualified.
